Smart Convenient Charging Wherever You Go
Smart 2CH Quick charger
CEC-2020(200kW Quick Charger)
Unique design identity
13.3” large LCD screen
User authentication through RFID method
Charging management system for living complex
Remote control through home-net mobile APP
User authentication through RFID method
Charging management system for living complex
Remote control through home-net mobile APP
13.3” large LCD screen
Unique design identity
Costel’s own design identity
13.3” large LCD screen
Easy and Fast GUI
Product name
Electric vehicle quick charger
model name
CEC-2020
Rated input
3-phase 4-wire, 380Vac, 324A, 60Hz, 213kW
Rated power
Independent charging : 1000Vdc, 200A 200kW
Simultaneous charging : 750Vdc, 130A 100kW(per channel)
Charging method
Combo 2 + Combo 2
Efficiency and power factor
93% or more / 0.95 or more
Touch panel
13.3-inch LCD & capacitive touch screen
User authentication
RF CARD
Status indication
Status LED
Communication function
LAN
Cooling method
Forced air cooling
size
700(W) ×1,800(H) × 900(D)
IP class
IP44
Safety function
Input/output overvoltage, overcurrent detection, temperature abnormality,
output leakage detection, emergency stop button
It is subject to change without notice due to the improvement of the appearance or function of the product.
