Smart Convenient Charging Wherever You Go
Smart 3WAY Quick charger
CEC-0530 BR/BC (50kW Quick Charger)
Unique design identity
13.3” large LCD screen
User authentication through RFID method
Charging management system for living complex
Remote control through home-net mobile APP
User authentication through RFID method
Charging management system for living complex
Remote control through home-net mobile APP
13.3” large LCD screen
Unique design identity
Costel’s own design identity
13.3” large LCD screen
Easy and Fast GUI
| Product name | CEC-0530 BR/BC | ||
|---|---|---|---|
| Charging type | rapid DC (CHAdeMo) |
rapid DC (SAE Combo Type 1) |
rapid AC (IEC 62196-2 Type 2) |
| Input | 3-phase 380VAC, 60㎐ | ||
| Output | DC 200~450V, 120A, 50kW | AC 380V, 63A, 43kW | |
| Environmental conditions |
temperature : -25℃ ~ 40℃ Humidity : 20% ~ 93% (however, there should be no condensation) |
||
| Operation Screen | 13” LCD Touch Screen (U/I) | ||
| User authentication | RF card or Credit Card | ||
| Charging time | within 30 minutes ( EV battery: based on 24kWh ) | ||
| Degree of protection | IP44 | ||
| Product size | 500(W) x 650(D) x 1600(H)mm | ||
| Certification | KC Certification , high efficiency energy equipment certification | ||
| Features | Improved power quality Built-in insulation transformer type | ||
| connector |  |
 |
 |
It is subject to change without notice due to the improvement of the appearance or function of the product.
