Smart Convenient Charging Wherever You Go
Electric vehicle/electric bus quick charger
2CH DISPENSER CEC-0020
2CH DISPENSER
Stable charging power supply dispenser
Supports single charging and simultaneous charging
User authentication through RFID method
Reinforced painting quality and durability even in external installation environments
Increased user visibility and improved user convenience by installing a 13-inch large LCD
Screen usage composition focusing on ease of use
Unique design identity
Costel’s own design identity
13.3” large LCD screen
Increased user visibility and improved user convenience by installing a 13-inch large LCD
Securing durability in external installation environment
Reinforced coating quality ensures durability even in external installation environments
RScreen usage composition focusing on ease of use
Easy and Fast GUI
Product name
Electric vehicle quick charger
model name
CEC-0020
Rated power
Independent charging : 1000Vdc, 200A 200kW
Simultaneous charging : 750Vdc, 200A 150kW(2 channels) / 75kw(4 channels)
Charging method
Combo 2 + Combo 2
Touch panel
13.3-inch LCD & capacitive touch screen
User authentication
RF CARD
Status indication
Status LED
Communication function
LAN
Cooling method
Forced air cooling
size
500(W) × 1600(H) × 320(D)
IP class
IP44
Safety function
Input/output overvoltage, overcurrent detection, temperature abnormality,
It is subject to change without notice due to the improvement of the appearance or function of the product.
